Authentic Motogadget mo.switch basic LED 2-Button | CNC Aluminum Illuminated Handlebar Switch
The next evolution of a bestseller has arrived for riders who demand a strict minimalist look paired with modern technology. The Motogadget mo.switch basic LED 2-button is CNC-milled from billet aluminum and anodized in a sleek, UV-resistant glossy black. The standout feature is its two high-quality black push-buttons, each elegantly ringed with standard white LED illumination (customizable in 5 different LED colors upon request), ensuring perfect visibility at night. The unit comes pre-wired with a 1.8m high-quality cable, allowing for quick and easy installation on either the left or right side of your handlebars.
TECHNICAL SPECIFICATIONS | Motogadget mo.switch basic LED 2-Button
| ATTRIBUTE | DETAILED SPECIFICATIONS |
|---|---|
| Brand | Motogadget (Made in Germany) |
| Design & Configuration | 2 black push-buttons with white LED illumination rings |
| Dimensions | Width 22 mm / Outer housing diameter approx. 45 mm |
| Handlebar Fitment | Compatible with 22.2 mm (7/8") or 25.4 mm (1") tubes |
| Material Construction | CNC billet aluminum, gloss black anodized housing, UV-resistant |
| Protection Rating | Highly robust push-buttons, protected against vibrations and splash water (IP65) |
| Connection Cable | Completely pre-wired internally with a high-quality 1.8 m cable |
| Current Limitation |
The product can handle currents of max. 1A |
CRITICAL INSTALLATION & WIRING GUIDE
The installation of this illuminated switch assembly requires strict adherence to the manufacturer's safety and wiring instructions:
-
Electronic Module Required: This product is not suitable to switch loads directly. All electrical loads must be switched by an electronic switching module (i.e., mo.unit).
-
Battery Safety: The vehicle battery must be completely disconnected prior to any work on the vehicle's electrical system. First, disconnect the negative terminal and then the positive terminal.
-
Incompatible Systems: Using the mo.switch with the plus pole connected to the vehicle frame (often found on older English motorcycles) is not possible.
-
Switching Mechanism: All push-buttons are designed to switch to earth (ground).
-
Wiring Scheme (For 2-Button Version):
-
Black Wire: Vehicle ground.
-
Red Wire: Terminal 15 (switched +12V), or AUX1/AUX2 of the mo.unit.
-
Brown Wire: Button A, switches to ground, connect to the desired mo.unit input.
-
Green Wire: Button B, switches to ground, connect to the desired mo.unit input.
-
