Domino Normally Opened Stop Switch (Part #2806.20.04) | Grey Plastic With Faston 2.8 Terminals
Are you in need of a compact, highly responsive, and durable brake light switch to replace or upgrade your current handlebar controls, Boss? Monkey89 presents the Domino Stop Switch (Part #2806.20.04). Engineered with a contact that remains opened at the rest position, this standardized component easily meets the strict requirements of various motorcycles, perfectly suiting On-road, Off-road, Vintage, Scooter, and ATV applications.
TECHNICAL SPECIFICATIONS | Domino Normally Opened Stop Switch
| ATTRIBUTE | DETAILED SPECIFICATIONS |
|---|---|
| Part Number (SKU) | 2806.20.04 |
| Switch Type |
Normally opened stop-switch |
| Body Material |
Constructed from grey plastic |
| Terminal Type |
Features feather faston 2.8 terminals |
| Rated / Max Voltage |
Nominal voltage of 12 VDC / Maximum functioning voltage of 14 VDC |
| Nominal Power |
2x21/5 W |
| Thread Specification |
Reduced thread sizing at 1/4"x32F/1" (UNEF-CL2A) designed specifically for fitting to "DOMINO'S" holders |
| Operating Temperature |
Dry working temperature ranging from -20°C to +60°C |
INSTALLATION GUIDE & CRITICAL TECHNICAL NOTES
To ensure accurate operation and maximize the lifespan of the switch, please note the following technical recommendations, Boss:
-
Application Limits: This specific kind of stop-switch can be fitted only to controls of motorcycles handlebars.
-
Torque Limitation: When threading the switch into the holder, the maximum tightening force must strictly not exceed 0.5 Nm.
-
Water Resistance Warning: The manufacturer explicitly notes that this is a no waterproof switch. Please be cautious when using high-pressure washers around the handlebar controls.
-
Electrical Durability: The switch is highly durable, boasting a voltage drop of less than 0.25V (at 2x21W) even after 50,000 operational cycles.
